Inteligentny generator elektrochirurgiczny z systemem zamykania naczyń ESU-P200

Model: ESU-P200

Wprowadzenie — Inteligentny generator elektrochirurgiczny z systemem zamykania naczyń

The ESU-P200 Intelligent Electrosurgical Generator with Vessel Sealing System is specifically designed for modern animal operating rooms, integrating high-frequency electrosurgical equipment and a vessel sealing system into a single, advanced unit.

Najważniejsze funkcje — ESU-P200

  • Intelligent Energy Management: Proprietary algorithms auto-adjust energy output and large vessel sealing based on tissue characteristics, improving precision and minimizing intraoperative damage/complications.
  • Efficient Bipolar Mode: Standard Mode is compatible with most devices with stable energy output. Intelligent Mode auto-adjusts voltage/power for fast cut/coag.
  • Multifunctional Integration: Supports various surgical instruments for long-term ROI. Expandable to ultrasonic scalpel/knife functions via HQS Vet platform.
  • Optimized Large Vessel Sealing: Compatible with sealing systems; intelligent algorithms ensure precise energy/pressure control for rapid, permanent closure.
  • Safe Return Electrode Monitoring System: Real-time negative plate contact check prevents current spikes, reducing burn risks. Auto-shuts down if pad detaches or contacts poorly.
  • Interactive Touchscreen: High-Resolution Touchscreen Interface allows fast setting and monitoring.
Cennik e-mailem

Wystarczy podać adres e-mail, a prześlemy ofertę i kartę katalogową tego modelu – zwykle w ciągu jednego dnia roboczego.

Share:

Model-specific documentation

Documents for ESU-P200

Check the covered model, language and document status before use. The manual supplied with the actual unit remains the controlling reference.

Product datasheet · English

ESU-P200 Intelligent Electrosurgical Generator with Vessel Sealing System product datasheet

Public PDF

HQS datasheet for the ESU-P200: product overview, features and the technical specifications published for this model. Confirm the ordered configuration in your quotation.

  • Product overview
  • Features
  • Technical specifications
Covered model
ESU-P200
Length
2 pages
File
PDF · 207 KB
Web copy prepared
Need a different language or configuration-specific document?

Inteligentny generator elektrochirurgiczny z systemem zamykania naczyń Specyfikacja

PARAMETER
SPECIFICATION
Power Input
AC 220V / 50Hz
Peak Power
200W
Dia. of Sealing Vessels
≤ 7mm
Type of Electrode
Multi-brand Compatibility
Weight of Generator
9.5kg
Dimensions
500mm*420mm*170mm
Monopolar Modes
7
Electrocision Modes
Pure Cut, Blend 1, Blend 2, Blend 3
Electrocoagulation Modes
Soft Coag, Spot Coag, Surface Coag
Bipolar Modes
Standard Mode , Intelligent Mode
Intelligent Vessel Sealing Modes
Manual Mode , Intelligent Mode

Konfiguracja

  • Main Generator
  • Electrosurgical Pencil
  • Silver-nickel alloy Bipolar Forceps
  • Foot Pedal
  • Power Cord
  • Reusable Negative Plate
  • Negative Plate Connecting Line
  • Monopolar Knife-shaped Electrode
  • Monopolar Spherical Electrode
  • Monopolar Annular Electrode
  • Monopolar Needle Electrode
  • Large-vessel Sealing Instrument (3 types for choice)

Opcje i akcesoria

  • Mobile Trolley
  • Negative Sticks 10mm
  • Negative Sticks 4mm
