Przenośny wideogastroskop/wideokolonoskop USB FEC-6000B

Model: FEC-6000B

Wprowadzenie — Przenośny wideogastroskop/wideokolonoskop USB

The FEC-6000B is a portable USB video gastroscope and colonoscope designed for use in bovine and equine applications. It features a durable polycarbonate handle, a washable pipe system to prevent blockages, and a convenient, removable suction valve for comfortable operation. The scope offers excellent maneuverability with an easily adjustable traction device for precise positioning and timely diagnosis. Its multi-coated, high-transmittance imaging system provides a wide field of view and clear images from 3-100mm, enhanced by a high-definition CMOS camera for superior diagnostic accuracy.

Najważniejsze funkcje — FEC-6000B

  • Multifunctional Gastroscope using polycarbonate new composite handle
  • Reasonable designed the clamp hole position
  • Washable pipe system can protect the lotion unobstructed, to prevent the pipeline blockage
  • Biopsy forceps hole to ensure the pliers and other devices unobstructed
  • Convenient, removable, safe and reliable suction valve
  • Excellent operation of the traction device can be easily transfer and adjust the bending parts to upward, downward
  • Scope with multi-coated high transmittance imaging system
  • Round field of view, wide viewing angle, wide field of view
  • 3 - 100 mm range can see more clear picture
  • High-definition CMOS camera makes users to get clearer, wide and bright image
Cennik e-mailem

Wystarczy podać adres e-mail, a prześlemy ofertę i kartę katalogową tego modelu – zwykle w ciągu jednego dnia roboczego.

Share:

Model-specific documentation

Documents for FEC-6000B

Check the covered model, language and document status before use. The manual supplied with the actual unit remains the controlling reference.

Product datasheet · English

FEC-6000B Portable USB Video Gastroscope/Colonoscope product datasheet

Public PDF

HQS datasheet for the FEC-6000B: product overview, features and the technical specifications published for this model. Confirm the ordered configuration in your quotation.

  • Product overview
  • Features
  • Technical specifications
Covered model
FEC-6000B
Length
3 pages
File
PDF · 340 KB
Web copy prepared
Need a different language or configuration-specific document?

Przenośny wideogastroskop/wideokolonoskop USB Specyfikacja

PARAMETER
SPECIFICATION
View of field
140°
Diameter of distal - end
Φ 12.8mm
Outer diameter of insert tube
Φ 12.8mm
Depth of view
3 - 100mm
Working length
3000mm
Working channel
Φ 3.2mm
LCD
Use computer LCD
Image solution
CMOS 1,000,000 pixels
Bending range
Up 180 °, Down 90 °, L/R 100 °
Voltage
220V - 240V
Frequency
50 - 60HZ
lamp Power
15V - 150W environmentally friendly halogen tungsten lamp
Illumination
70000LX (using special measuring tools)
Color Temperature
3000~7000K
Air Pump Pressure
30 - 60kpa
Air Flow
4L/min - 10L/min (Quiet pump)

Porównanie modeli z tej serii

Różnice podano na podstawie specyfikacji opublikowanych dla poszczególnych modeli. Ostateczną konfigurację prosimy potwierdzić w ofercie.

Ten model należy do serii FEC-800. Na stronie serii zestawiono wszystkie modele. Przegląd serii

Opublikowane specyfikacje nie wskazują różnych wartości dla tych modeli. W sprawie karty katalogowej konkretnego modelu prosimy o kontakt.

Konfiguracja

  • Portable Gastroscope set
  • Biopsy forceps set
  • Cleaning brush set
  • Leak detector set
  • Attract valve anti jet cover set
  • Endoscope case set
  • Mini pump (Portable) set
  • Charge set
  • User manual
  • Certificate

Opcje i akcesoria

  • Laptop computer HUAWEI MateBook D 14 SE
  • Light cold source machine
  • Trolley
