Features
1.Medical-Grade Nebulization Performance
Delivers fine, therapeutic-grade mist particles that effectively reach the upper airways, trachea, alveoli, and lower respiratory tract, ensuring optimal respiratory care coverage.
2.Consistent & Gentle Nebulization
Stable mist output prevents throat irritation, with smooth, continuous operation for uninterrupted therapy.
Oil-free lubricated piston pump enhances durability and promotes healthier, longer-lasting performance.
3.Pet-Friendly & Hygienic Design
Soft, hypoallergenic mask material ensures comfort, is odor-free, and supports daily disinfection for safe reuse.
Eco-friendly construction maintains safety even with repeated long-term use.
4.Versatile Drug Compatibility
Water-free nebulization technology works seamlessly with a wide range of medications, preserving efficacy.
5.Efficient Cooling System
Mesh cooling design ensures effective heat dissipation, enabling 24/7 stable operation with intermittent use.
Extended lifespan even under prolonged workloads
Technical Specifications
PARAMETER | SPECIFICATION |
Power supply | Input: AC220V,50Hz |
Maximum atomization rate | 0.2mL/ min |
The residual amount of liquid medicine | ≤1.0mL |
Mist particle size(MMD) | 4um ± 25% |
Output pressure | 60-130kPa |
Fuse tube | T2A/ 250VΦ2×10 |
Free flow of compression pump | ≥4.5L/ min |
Noise | ≤60dB(A) |
Input power | ≤100W |
Safety classification | -Equipment that cannot be used in the -presence of flammable anesthetic gas -mixed with air or flammable anesthetic -gas mixed with oxygen or nitrous oxide |
Protection level | IPX0 |
Contraindications | None |
Dimension | L 15 x W 15 x H 9CM |
Weight (without battery) | About 1250g (without battery) |
Normal operating conditions | -Temperature range: 5°C ~ 40°C -Relative humidity range: 30%~80% -Atmospheric pressure range: 86kPa~106kPa |
Transportation and storage environment restrictions | Ambient temperature range: -20°C~+55°C |
Relative humidity range: 10%~93% | |
Atmospheric pressure range: 70kPa~106kPa |
