The Veterinary Blood and Infusion Warmer is designed to warm blood or fluids, providing relief in hypothermia cases for veterinary use. It efficiently transmits heat to the IV set, reaching a preset temperature with a deviation within ±1°C, making it widely applicable for blood or infusion transfusions. This warmer offers warm care in cold environments.
Model-specific documentation
Check the covered model, language and document status before use. The manual supplied with the actual unit remains the controlling reference.
Product datasheet · English
HQS datasheet for the H-110C: product overview, features and the technical specifications published for this model. Confirm the ordered configuration in your quotation.
PARAMETER | SPECIFICATION |
|---|---|
Temperature Setting ° C | 35.0° C ~ 42.0° C |
° F | 95.0 ° F~ 107.6 ° F |
Temperature Accuracy ° C | ≤ ±1°C |
° F | ≤±1 .8 ° F |
Increment ° C | 0. 1° C |
° F | 0.2 ° F |
Optional Unit | ° C or ° F |
Warming Up Time | ≤ 2 mins |
Overheat Protection | 46 ° C ,hardware and software protection |
Alarm | Overheat, low temperature, system error, door open, warming up alarm |
Installation Way | IV Knob |
Power Supply Input | 100 - 240V(AC Power),50/60HZ,0.3 - 0.7A |
Output | 12V(DC Power) 2.5A |
Power Consumption | 85VA |
Operating Environment Temp. | +5° C - +30° C |
Relative Humidity | 20% - 80% |
Atmosphere | 76.0kPa - 106.0kPa |
Transportation and Storage Environment Temp. | - 20 ° C - + 55 ° C |
Relative Humidity | 1 0% - 93 % |
Atmosphere | 50.0kPa - 106.0kPa |
Degree of Protection against Ingress of Liquids | IPX1 |
Degree of Protection against Electric Shock | Class II, Type CF |
Dimension | 180x70x35mm |
Net Weight | 0.2kg; with knob:0.4kg |
Aşağıdaki farklar, her model için yayımlanan teknik özelliklerden alınmıştır. Nihai konfigürasyonu teklifinizde teyit edin.
| Parametre | H-110CBu model | H-110V |
|---|---|---|
| ° F | 95.0 ° F~ 107.6 ° F | 86.9 ° F~ 107.6 ° F |
| Warming Up Time | ≤ 2 mins | ﹤ 4 mins |
