Advantages
Appointment Timing Function: A new scheduling feature has been introduced to eliminate waiting time during startup or shutdown. Users can set delayed shutdown after sterilization, as well as schedule fan activation or UV sterilization. The adjustable time range spans from 0 to 99 hours and 59 minutes.
Negative Pressure Airflow Design: The biosafety cabinet’s left, right, and rear walls incorporate negative pressure air ducts. This design creates an air curtain and a dual-layer barrier between the workspace and the external environment. Additionally, the negative pressure surrounding the work area ensures zero leakage of hazardous materials.
Durable Construction: The cabinet frame is constructed from cold-rolled steel plate for enhanced structural integrity. The work surface and interior lining are made of stainless steel, combining aesthetic appeal with corrosion resistance. The support stand is metal-based and features an electrostatic spray-coated finish.
User-Friendly Controls: The control panel employs touch-sensitive switches, ensuring both sleek aesthetics and intuitive operation.
Specifications
MODEL | BSC-1100IIB2 | BSC-1300IIB2 | BSC-1500IIB2 | BSC-1800IIB2 | |
External Size (W*D*H) (mm) | 1100*750*2250 | 1300*750*2250 | 1500*750*2250 | 1800*775*2250 | |
Internal Size (W*D*H) (mm) | 940*600*660 | 1150*600*660 | 1350*600*660 | 1625*600*660 | |
Tested Opening | Safety Height 200 mm (8") | ||||
Max Opening | 420 mm (17") | 420 mm (17") | 500mm (20") | 480mm (20") | |
Inflow Velocity | 0.53±0.025 m/s | ||||
Downflow Velocity | 0.33±0.025 m/s | ||||
ULPA Filter | Two, 99.9995% efficient at 0.12 um. Filter life indicator. | ||||
Front Window | Motorized. Two-layer laminated toughened glass ≥6mm. Anti UV | ||||
Noise | NSF49≤61dB / EN12469≤58 dB | ||||
UV Lamp | 30W*1 | 30W*1 | 40W*1 | 40W*1 | |
UV timer, UV life indicator, emission of 253.7 nanometers for most efficient decontamination. | |||||
Illuminating Lamp | LED lamp | ||||
12W× 2 | 12W× 2 | 16W× 2 | 16W*2 | ||
Illumination | ≥1000Lux | ||||
Consumption | 800W | 850W | 1300W | 1300W | |
Waterproof Socket | Two, total load of two sockets: 500W | ||||
Display | LCD display: exhaust filter and downflow filter pressure, filter and UV lamp working time, inflow and down flow velocity, filter life, humidity and temperature, system working time etc. | ||||
Control System | Microprocessor | ||||
Airflow System | 0% air re-circulation, 100% air exhaust | ||||
Alarm | Abnormal airflow velocity; filter replacement; front window at unsafe height; high filter pressure alarm. | ||||
Visual and Audio Alarm | Filter replacement, window over height, abnormal air flow velocity. | ||||
Exhaust Duct | 4 meters PVC duct, Diameter: 300mm | ||||
Material | Work Zone: 304 stainless steel | ||||
Main Body: Cold-rolled steel with anti-bacteria powder coating. | |||||
Work Surface Height | 750mm (size can be customized according to requirements) | ||||
Caster | Footmaster caster | ||||
Power Supply | 110/220V±10%, 60/50Hz (110V/60Hz is not applicable to ABS-1800IIB2) | ||||
Standard Accessory | illuminating lamp, UV lamp*2, base stand, remote control, foot switch, exhaust blower, exhaust duct, drain valve, waterproof sockets*2, pipe strap*2. | ||||
Optional Accessory | Water and gas tap, electric height adjustable base stand | ||||
Gross Weight | 240kg | 280kg | 300kg | 408kg | |
Package (mm) | Main Body (W*D*H) | 1220*1000*1820 | 1460*1000*1820 | 1630*1000*1820 | 1930*1000*1820 |
Exhaust Blower (W*D*H) | 970*810*630 | 970*810*630 | 970*810*630 | 970*810*680 | |
